491
LCD Option Board Function Section 8-6
9. Use the Down or Up button to select the character of each digit.
Name the text string to elevator.
10. Press the OK button to save the setting.
11. Press the ESC or OK button to return to the User Monitor Setup Screen.
12. Press the ESC button three times to return to the Monitor Mode.
Switch to the User Monitor Screen 2.
Note 1. The default text string is NULL.
2. The max length of text string is 12 characters.
Changing User Monitor Screen
User can not only change the date displayed in the User Monitor Screen in the
Setup Mode, but also in the Monitor Mode.
Example 1 Change the average to 0100 and the minimum to -00123.
1,2,3...
1. Display the User Monitor Screen.
2. Press the Forward + OK button simultaneously to enter the Data Change
Screen.
The column cursor will be flashing on the digit before the value.
3. Use the Forward button to move the column cursor to the digit to be set.
