Omron CP1H CPU User Manual

542
Memory Allocations Section 9-9
FINS/ TCP Port Settings
FINS/TCP Connection
No.1 to 2
Each FINS/TCP connection number has 5 bytes. The configuration of the 5
bytes of data in each number is as shown in the following diagram.
HTTP Server Setup
If the password for accessing the Ethernet Option Board’s Web page is forgot-
ten, find out it in this area. It is written in ASCII format.
FINS Node Address
Using IP Address
Display/Setting Area
The IP address is (1)(2).(3)(4).(5)(6).(7)(8) (hex)
If the local IP address in the system setup is set to a value other than 0.0.0.0,
this area will act as an IP address display area and the local IP address in the
system setup will be read and stored here when the power is turned ON or the
Ethernet Option Board restarted.
If the local IP address in the system setup is set to 0.0.0.0, this area will act as
an IP address setting area. The value will be read by the Ethernet Option
Board when the power is turned ON or the Ethernet Option Board restarted
and is used as the local IP address.
If the IP address for accessing the Ethernet Option Board through Web browser
is forgotten, find out it in th
is area.
Note When IP address in system setup area and DM area are all set to 0.0.0.0, the
IP address will be 192.168.250.1 (FINS node address).
n+138 000000
0
000000000
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Protect setting
Bit Settings Unit operation
0 to 4 Reserved Always 0.
5 Protect setting 0: The IP address of FINS/TCP connection No.2 is not
under the protection.
6 to 15 Reserved Always 0.
Destination IP address Auto-allocated
FINS node
Offset 15 8 7 0
n+149
HTTP Password
⋅⋅⋅
n+152
n+153 HTTP Port number
n+154
FINS node address (hex)
The setting range is 0~ FE (hex).
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
n+155
n+156
(1)(2) (3)(4)
(5)(6) (7)(8)
