System Configuration Section 1-2
â– Restrictions for the Ambient Temperature
Restrictions in the System Configuration
Configure the system within the restrictions for the output load current, simul-
taneously ON inputs, and total power consumption.
Power Supply Voltage Specifications for CPU Units with DC Power and
Transistor Outputs
When connecting CP-series Expansion I/O Units with Relay Outputs to CPU
Units with DC Power and Transistor Outputs (CP1H-X40DT(1)-D, CP1H-
XA40DT(1)-D, and CP1H-Y40DT(1)-D), use a power supply voltage of
24 VDC ±10% if connecting more than three Expansion I/O Units or if the
ambient temperature is greater than 45°C.
Mounting Restriction
When connecting CP-series Expansion Units or Expansion I/O Units, provide
a space of approximately 10 mm between the CPU Unit and the first Expan-
sion Unit or Expansion I/O Unit.
If sufficient space cannot be provided between the CPU Unit and the first
Expansion Unit or Expansion I/O Unit, reduce the temperatures in the above
derating curves for the output load current, number of simultaneously ON
inputs, and total power consumption by 5°C.
Model Output load current Simultaneously ON inputs Total power
consumption
CP1H-X40DT-D
CP1H-X40DT1-D
CP1H-XA40DT-D
CP1H-XA40DT1-D
CP1H-Y20DT-D
CP1H-X40DR-A
CP1H-XA40DR-A
100%
67%
50 55
Ambient temperature (°C)
100%
Input voltage:
26.4 V
55
Ambient temperature (°C)
100%
55
Ambient temperature (°C)
100%
75%
47
55
Ambient temperature (°C)
100%
67%
47
55
Ambient temperature (°C)
Input voltage: 24 V
Input voltage:
26.4 V
100%
75%
47 55
Ambient temperature (°C
10 mm
CP1H CPU Unit
Expansion I/O Units or Expansion Units
