PLC Setup Appendix G
FINS Protection Settings
Settings for FINS Write Protection via Network
Name Default Settings When setting is read
by CPU Unit
Internal
address
Bits Settings
1 Validate FINS write pro-
tection via network
Disable. Disable. Every cycle 448 15 0
Enable. 1
1-1 Nodes excluded
from protection tar-
gets
--- --- --- --- --- ---
1-1-1 Network
Address
0 0 Every cycle 449 08 to
15
00 hex
: :
127 7F hex
1-1-2 Node
Address
1 1 Every cycle 449 00 to
07
01 hex
: :
254 FE hex
All nodes FF hex
1-2 Nodes excluded
from protection tar-
gets
--- --- --- --- --- ---
1-2-1 Network
Address
0 0 Every cycle 450 08 to
15
00 hex
: :
127 7F hex
1-2-2 Node
Address
1 1 Every cycle 450 00 to
07
01 hex
: :
254 FE hex
All nodes FF hex
--- --- --- --- --- --- --- --- ---
1-32 Nodes excluded
from protection tar-
gets
--- --- --- --- --- ---
1-32-1 Network
Address
0 0 Every cycle 480 08 to
15
00 hex
: :
127 7F hex
1-32-2 Node
Address
1 1 Every cycle 480 00 to
07
01 hex
: :
254 FE hex
All nodes FF hex
