Specifications Section 2-2
Setting Input Functions in
the PLC Setup
Functions for the normal input terminals in the built-in inputs can be individu-
ally allocated by making selections in the PLC Setup.
Note Set using the MSKS instruction in direct mode or counter mode.
Input
terminal
block
Input operation High-speed counter
operation
Origin search function
Word Bit Normal inputs Interrupt inputs
(See note.)
Quick-
response
inputs
High-speed counters 0
to 3 set to be used.
Origin search function
for pulse outputs 0 to 3
set to be used.
CIO 0 00 Normal input 0 Interrupt input 0 Quick-response
input 0
--- Pulse 0: Origin input sig-
nal
01 Normal input 1 Interrupt input 1 Quick-response
input 1
High-speed counter 2
(phase-Z/reset)
Pulse 0: Origin proximity
input signal
02 Normal input 2 Interrupt input 2 Quick-response
input 2
High-speed counter 1
(phase-Z/reset)
Pulse output 1: Origin
input signal
03 Normal input 3 Interrupt input 3 Quick-response
input 3
High-speed counter 0
(phase-Z/reset)
Pulse output 1: Origin
proximity input signal
04 Normal input 4 --- --- High-speed counter 2
(phase-A, increment, or
count input)
---
05 Normal input 5 --- --- High-speed counter 2
(phase-B, decrement, or
direction input)
---
06 Normal input 6 --- --- High-speed counter 1
(phase-A, increment, or
count input)
---
07 Normal input 7 --- --- High-speed counter 1
(phase-B, decrement, or
direction input)
---
08 Normal input 8 --- --- High-speed counter 0
(phase-A, increment, or
count input)
---
09 Normal input 9 --- --- High-speed counter 0
(phase-B, decrement, or
direction input)
---
10 Normal input 10 --- --- High-speed counter 3
(phase-A, increment, or
count input)
---
11 Normal input 11 --- --- High-speed counter 3
(phase-B, decrement, or
direction input)
---
CIO 1 00 Normal input 12 Interrupt input 4 Quick-response
input 4
High-speed counter 3
(phase-Z/reset)
Pulse output 2: Origin
input signal
01 Normal input 13 Interrupt input 5 Quick-response
input 5
--- Pulse output 2: Origin
proximity input signal
02 Normal input 14 Interrupt input 6 Quick-response
input 6
--- Pulse output 3: Origin
input signal
03 Normal input 15 Interrupt input 7 Quick-response
input 7
--- Pulse output 3: Origin
proximity input signal
04 Normal input 16 --- --- --- ---
05 Normal input 17 --- --- --- ---
06 Normal input 18 --- --- --- ---
07 Normal input 19 --- --- --- ---
08 Normal input 20 --- --- --- ---
09 Normal input 21 --- --- --- ---
10 Normal input 22 --- --- --- ---
11 Normal input 23 --- --- --- ---
To Next Page
