6-7 Master Parameter Editing Details (Tab Descriptions)
6-7-4 Canceling Slave Registration with the Master
6-7-4 Canceling Slave Registration with the Master
Component - Parameter - Edit - General Tab - Register/Unregistered
(Allocate/Unallocated) Button
Note: This procedure is the same for the CS1W-DRM21(-V1), CJ1W-DRM21,
CVM1-DRM21-V1, C200HW-DRM21-V1, and 3G8F7-DRM21.
The General Tab Page is used to register slaves with the master or unregister slaves.
To register or unregister a slave, use the following procedure.
1. Select the slave to be registered or unregistered.
2. Click the
Register or Unregister Button.
An unregistered slave will be displayed in the Unregistered Device List.
A registered slave will be displayed in the Registered Device List.
6-7-5 Automatic Allocation with Registration
Component - Parameter - Edit - General Tab - Auto allocation as is
registered - Register/Unregistered (Allocate/Unallocated) Button
Note: This procedure is the same for the CS1W-DRM21(-V1), CJ1W-DRM21,
CVM1-DRM21-V1, and C200HW-DRM21-V1.
• If the
Auto allocation as is registered Box is checked when the slaves are registered
with the master in the Edit Device Parameters Dialog Box, the I/O allocation of the
slaves will be made in units of words automatically in order of registration. This
checkbox will be enabled in the Edit Device Parameters Dialog Box only. The
automatic allocation of the slaves will be made in units of words automatically in order
of registration beginning with the unoccupied area of block 1 of the corresponding
memory block.
• It is possible to unregister the I/O allocation of the selected slaves or to make the I/O
reallocation of the slaves in the order of earlier addresses anytime by clicking on
Register/Unregistered Button. The advanced setup function (explained later) will not
be available if automatic allocation is selected.
6-28
