2-9 File Operations
2-9-1 Overview
2-9 File Operations
2-9-1 Overview
The following files can be saved and read by the CX-Integrator.
File name
File name
extension
Contents
Storage location
when downloaded
Project files .cin Connection information to the Relay
PLC
Overall network configuration of the
target PLC including parameters
---
Network structure
files
.npf DeviceNet configuration of the
target PLC including parameters
Note: Each file contains only
one network.
All DeviceNet
slaves on the
network
Network
configuration
files
Controller Link
node files
.csv Network configuration for Controller
Link networks connected directly to
the target PLC
---
DeviceNet device
parameter files
.dvf Parameters for individual DeviceNet
devices (master or slave)
All DeviceNet
slaves
Component
parameter
files
CompoWay/F
component
parameter files
.xml Parameters for all components
except for DeviceNet devices
Note: These files do not
include Temperature Controller
information.
All components
Controller Link
data link table files
.cl2 Controller Link user-set data link
tables
CPU Bus Unit
setup area in the
parameter area of
the CPU Unit
Data link
files
SYSMAC LINK
data link table files
.sl3 SYSMAC LINK user-set data link
tables
CPU Bus Unit
setup area in the
parameter area of
the CPU Unit
FINS local routing table files .rtg Routing tables of the target PLC Parameter area in
the CPU Unit
Note
Network configurations and device parameters can be saved individually in network
configuration files and component parameter files.
Doing so will enable quicker system recovery when a failed device is replaced because
the parameter file can be read to quickly reset the replaced device.
2-45
