1-5 Window Descriptions
1-5-1 Starting Methods
1-5 Window Descriptions
1-5-1 Starting Methods
The CX-Integrator can be started with any of the following three methods.
1) When using the CX-Programmer Ver. 6.0 or later, select Tools
−
Network Settings.
2) When using the CX-Programmer that was installed from the CX-One, right-click a
Communication Unit in the CX-Programmer’s I/O table display and select Start Special
Application from the pop-up menu.
Note: If the Communication Unit is a Serial Communications Board/Unit, a Start Special Application
Dialog Box will be displayed. Select CX-Integrator in the dialog box to start the CX-Integrator.
3) Select CX-Integrator from the Start Menu.
1-5-2 Main Window
One of the following windows will appear when the CX-Integrator is started.
Offline Window
Network Configuration Window
Workspace Window
Online Window
Network Configuration Window
Workspace Window
Online Connection
Information Window
Output Window
1-22
