6-5 Editing Master Parameters
6-5
Editing Master Parameters
Device parameters are classified into master device parameters and slave device
parameters. This section description provides information on how to edit master device
parameters.
The master device parameters that can be edited include slave device I/O allocations
to the master, communication cycle time settings, and connection settings.
The following two methods can be used to edit parameters for the master.
1) Parameter Wizard
The Parameter Wizard is an interactive interface that makes I/O allocations
possible in order of node addresses.
2) Editing Parameters
Parameters can be edited to allocate I/O and make settings as required,
including the communication cycle time, connection, and device information
check settings.
The CX-Integrator allows settings, such as the following function settings, for the
OMRON CS1W-DRM21(-V1) DeviceNet Unit, CJ1W-DRM21 DeviceNet Unit,
CVM1-DRM21-V1 DeviceNet Master Unit, and C200HW-DRM21-V1 DeviceNet Master
Unit.
When transferring parameters edited for the CVM1-DRM21-V1,C200HW-DRM21-V1,
or 3G8F7-DRM21, however, they can be transferred from the CX-Integrator only by
going through a CS/CJ-series PLC.
Setting method
Function
Parameter Wizard
(Component - Parameter
- Wizard)
Parameter editing
(Component -
Parameter - Edit)
CS1W-DRM21 (-V1) or
CJ1W-DRM21
C200HW-DRM21-V1 or
CVM1-DRM21-V1
I/O Allocations Parameter Wizard I/O Allocation (OUT) and
I/O Allocation (IN) Tabs
OK OK
Communication Cycle
Time
Communication Cycle
Time Tab
OK OK
Connections OK No
Device Information
Compare
Advanced Setup Button
in General Tab
OK No
Message Timer Message Timer Tab OK No
Slave Function Slave Function Tab OK No
Startup Remote I/O
Communications
(See note 1.) OK
Explicit Message
Communications
---
General Tab
(See note 2.) OK
Note 1. The same function can be achieved with the setting to enable/disable the master
function.
2. Explicit message communications is possible whether or not registration has been
made on the scan list.
Note
When editing parameters on the CX-Integrator for the CVM1-DRM21-V1,
C200HW-DRM21-V1, or 3G8F7-DRM21, download them to the Master Unit by going
through a CS/CJ-series PLC.
Note
Before making device I/O allocations to the master, the device must be added to the
Network Configuration Window, regardless of whether or not it has been registered as
a slave with the master. Refer to 2-5 Creating Virtual Network Configurations Offline for
information on creating a virtual network.
6-15
