Omron CX-INTEGRATOR - V1.1 User Manual

2-7 Uploading, Downloading, and Comparing Network Parameters
2-7-1 Overview
2-7 Uploading, Downloading, and Comparing Net-
work Parameters
2-7-1 Overview
With the CX-Integrator, the parameters of networks in the Workspace Window can be
uploaded from, downloaded to, and compared with the parameters of the actual
network.
Applicable Networks
The networks and parameters for which network parameters can be uploaded,
downloaded, and compared are listed in the following table.
Network Parameters
Controller Link networks Network parameters:
Maximum node address, number of polling nodes, allowable
number of send/receive frames
SYSMAC LINK networks Network parameters:
Communications cycle time, maximum node address, number
of polling nodes, allowable number of send/receive frames
2-7-2 Procedure
Setting Parameters Offline
To set parameters offline, right-click a network in the Workspace Window and select
Parameter
− Edit. The Edit Parameter Dialog Box will be displayed. The network
parameters can be set in this dialog box.
Downloading and Uploading Parameters from Actual Networks
Downloading
To download the parameters set for the virtual network on the computer to an actual
network, right-click the network in the Workspace Window and select Parameter –
Transfer [PC to Network] from the pop-up menu. The parameters will be downloaded
to the actual network with the same network address.
Uploading
To upload the parameters set for the actual network to the virtual network on the
computer, right-click the network in the Workspace Window and select Parameter -
Transfer [Network to PC] from the pop-up menu. The parameters will be uploaded
from the actual network with the same network address.
Comparing
To compare the parameters set for the virtual network on the computer to the
parameters of an actual network, right-click the network in the Workspace Window
and select Parameter - Compare from the pop-up menu. The parameters set for the
virtual network on the computer will be compared with those set in the actual network
with the same network address.
2-43
