6-16 Optional Functions
6-16-1 Installing Expansion Modules
6-16 Optional Functions
The optional functions make it possible to set Expansion Modules in the CX-Integrator
for new devices, add DeviceNet device vendors, and add new device types.
6-16-1 Installing Expansion Modules
Tools - DeviceNet tool - Install Plugin Module
To install the expansion module, use the following procedure.
1. Select Tools - DeviceNet tool - Install Plugin Module.
A window to specify the name of expansion module set file will be displayed.
2. Input the file name and click the Open Button.
The Expansion Module will be added to the CX-Integrator.
6-16-2 Adding Vendors and Device Types
Option - Edit Configuration File
Use the following procedure to add a new device vendor or device type.
1. Select Option and Edit Configuration File.
2. Select Vendor ID/Device Type List.
The following dialog box will be displayed.
3. To add or modify the vendor information, click on the Vendor Tab.
To add new vendor information, use the following procedure.
1) Click the New Button.
The following dialog box will be displayed.
2) Input the new vendor ID and vendor name and click the OK Button.
The new vendor will be added to the list.
6-72
