2-6 Manipulating Component Parameters
2-6-1 Overview
2-6 Manipulating Component Parameters
2-6-1 Overview
With the CX-Integrator, the parameters on components in the Network Configuration
Window can be set. They can also be uploaded from, downloaded to, and compared
with the parameters of the components on the actual network.
Applicable Components and Parameters
The components and parameters that can be manipulated are listed in the following
table.
Component Parameters
CPU Unit Part of the PLC Setup:
Communications settings for the peripheral and RS-232C ports
and FINS protection settings
Serial Communications
Boards/Units
Serial port communications settings
Controller Link Units Unit communications settings and data link settings
SYSMAC LINK Units Unit communications settings and data link settings
Ethernet Units Unit communications settings
CompoWay/F slaves CompoWay/F slave device parameters
DeviceNet Units DeviceNet Unit device parameters
DeviceNet slaves DeviceNet slave device parameters
Note: The applicable component (Unit) when a PLC is selected on a Network Configuration
Window depends on the type of communications and the serial port being used, as
shown in the following table.
Communications Applicable Unit
Ethernet Ethernet Unit
Controller Link Controller Link Unit
SYSMAC LINK SYSMAC LINK Unit
CompoWay/F
NT Link
• Serial port on CPU Unit: CPU Unit
• Serial port on Serial Communications Unit/Board:
Serial Communications Unit/Board
2-38
