1-4 PLC Connecting Cables
1-4-2 Direct Connections to a Relay PLC via a Network
1-4-2 Direct Connections to a Relay PLC via a Network
When connecting the computer running the CX-Integrator directly to the relay PLC via a
network, make the connection correctly using the following connection diagrams.
Ethernet
Ethernet port
Ethernet
CS/CJ-series
Ethernet Unit
CS/CJ-series
relay PLC
DeviceNet network
Controller Link or SYSMAC LINK
Controller Link
CS/CJ-series
Controller Link Unit
CS/CJ-series
relay PLC
DeviceNet network
PCI Controller Link Support Board
(See note.)
Note:
Type Board Model
Optical ring with H-PCF cable 3G8F7-CLK12-V1
Optical ring with GI cable 3G8F7-CLK52-V1
Wired (twisted-pair cable)
Controller Link PCI-bus
Support Board
3G8F7-CLK21-V1
1-21
