6-12 Downloading the Network Configuration/Device Parameters to Devices
6-12-3 Resetting the Device
6-12-3 Resetting the Device
Component - Reset
To enable the new settings, use the following procedure to reset the network device.
1. Place the CX-Integrator online.
2. Select the device in the Network Configuration Window.
3. Select Device - Reset.
The following confirmation dialog box will be displayed.
4. Click the Yes Button.
The progress window will be displayed and the devices will be reset.
The new settings will be valid after the devices have been reset.
Note
When the devices are reset, communications errors will temporarily occur. For this
reason, do not reset the devices while the master-side PLC (CPU Unit) is operating.
6-56
