1-2 Specifications
1-2-1 CX-Integrator Specifications
Item Specification
Either of the following can be used.
Serial
communications
Direction connection is possible to any of the following serial ports on a
CS/CJ-series PLC.
• CPU Unit peripheral port (Toolbus or Host Link)
• CPU Unit RS-232C port (Toolbus or Host Link)
• CPU Unit USB port (CP Series only)
• Serial Communications Board or Serial Communications Unit RS-232C
port or RS-422A/485 port (Host Link)
Direct connection is possible to any of the following serial ports on an
NSJ-series NSJ Controller.
• RS-232C port A (Toolbus) on NSJ Controller
• RS-232C port B (Toolbus) on NSJ Controller
• USB port on NSJ Controller
Note: Automatic online connection is possible for serial communications
ports. (The user does not have to set the computer communications
settings.) The communications settings will be automatically set to
those of the PLC. Connection is possible to a serial port on the CPU
Unit, a Serial Communications Board, or a Serial Communications
Unit. For PLC serial ports, however, only the Toolbus or Host Link
serial communications modes can be used and the baud rate must be
9600, 19200, 38400, or 115200 bits/s.
Connecting to the
Relay PLC
FINS network
communications
Direction connection is possible through any of the following networks on
a CS/CJ-series PLC or NSJ-series NSJ Controller.
• Ethernet (Ethernet, Ethernet FINS/TCP, or FinsGateway)
• Controller Link (Controller Link or FinsGateway)
• SYSMAC LINK (SYSMAC LINK or FinsGateway)
1-9
