1-2 Specifications
1-2-2 Files Created by the CX-Integrator
File name Contents Details
FINS local routing
table files (.rtg)
Routing tables of the target PLC
Note: These are the same as the FINS local routing table files (.rtg) created
with the CX-Net. Files created with the CX-Net can be imported.
Routing table files
FINS network
routing table files
(.rt3)
Routing tables for all PLCs on networks to which the target PLC belongs
Note: These are the same as the FINS network routing table files (.rt3)
created with the CX-Net. Files created with the CX-Net can be
imported.
Note
With DeviceNet only, the following files can also be exported and saved.
EDS files (.eds)
The device list saved in CSV format (.csv)
The I/O comments saved in CSV format (.csv)
The device parameters of an OMRON DeviceNet Master Unit saved as an Open
Network Controller DRM_UNIT (virtual unit) file
The device parameters of an OMRON DeviceNet Master Unit saved as a NetX Server
(NetX Server for DeviceNet) file
Note
The CX-Integrator does not support files created in the DeviceNet Configurator Ver.
1.0 file format.
1-13
