2-4 Switching the Target PLC
2-4-2 Procedure
3. Right-click a PLC on the network and select Connect to this PLC from the pop-up
menu.
Right-click the PLC for which the
network structure is to be uploaded
and select Connect to this PLC from
the
p
o
p
-u
p
menu.
Network Structure Window
The selected PLC will be set as the target PLC.
Here, the target PLC is
switched to this PLC.
Example: CS1G-CPU45H
The new target PLC
can be confirmed here.
4. Right-click a Communications Unit/port from the new target PLC and select
Transfer [Network to PC] to upload the network configuration.
2-28
