• Power supply for the Sensor Controller of FH and the Smart Camera of FHV
• Software data for the version-up tool of the Remote Operation.
Precautions for Correct Use
There are two types in the software data for the version-up tool of the Remote Operation: One
is for the FH series and another is for the FHV series. Prepare the appropriate software data
tool for your update.
Preparation
Precautions for Correct Use
Do not apply any changes to the software data file. The tool will check its size stored in the PC.
If there are unnecessary files or folder in it,the update will fail.
1 Install the version of the Remote Operation tool on the PC as same as the current measure-
ment application for the Sensor Controller.
2
Store the software data for the version-up tool of the Remote Operation on the same PC.
The version-up tool can use the software data to update even if it is stored in any storage on its
network where the PC can access.
If the software data is stored in an FTP server, the tool cannot use it to update.
Updating the Version
The RAMDisk is used when the update is performed with the Remote Operation Tool. When the RAM-
Disk is used for Image Logging, restart it to start the procedures with the empty RAMDisk.
1 Connect to the Sensor controller using the Remote Operation tool.
2 Select the System information on the Function drop-down menu and click Version-up.
3 Basic Operations
3 - 46
FH/FHV Series Vision System User’s Manual (Z365-E1)
