• Is the camera cable connected correctly?
• Is the lens aperture the maximum or the minimum?
• Is the camera's shutter speed correct?
• Is the lighting method correct?
Start-up is slow.
• Was the system connected to a LAN when started?
If the system is started while connected to a LAN, startup may take a longer time.
Additional Information
When Touch Panel Monitor (FH-MT12) is selected from the Serial (RS-232C/422)box in the
Communication module select section under Startup setting, and if a RS-232C cable and a
Touch Panel Monitor are not connected to the Sensor Controller, starting the application takes
approximately 30 seconds longer than usual.
The date and time are abnormal.
• In the case of the FHV series, do you set the date and time?
In the FHV series, it is necessary to set the date and time each time it is activated.
11-2-2
During Operation
Measurement results do not display on the monitor.
• Are windows other than the Main screen (the Edit Flow window, etc.) displayed?
• Are any setting windows open?
* A setting window is defined as a window that opens separately such as the Edit Flow window and
the Scene Maintenance window.
"NG (memory shortage)" is displayed in the Detail result area.
• Does the number of specific processing items, such as camera image input, exceed the limit?
Data cannot be saved.
• The data save may have failed because there was not enough free capacity in the flash memory in
the controller. The current scene group data in the controller memory is destroyed after the restart.
Immediately perform one of the recovery/avoidance procedures specified below.
- For example, reduce the memory usage and then save data again to the controller, delete scenes,
delete processing units, adjust the processing unit measurement area, or adjust the sizes of regis-
tered models.
- Evacuate the current scene group data to the external memory.
Click Function menu - Save to file - Setting data - Scene group data.
11 What to Do!
11 - 10
FH/FHV Series Vision System User’s Manual (Z365-E1)
