6-4
Analyzing Inspection and Measure-
ment Results [NG Analyzer]
The NG Analyzer is a tool for analyzing NG factors using images.
Start the NG analyzer by selecting Tool - NG analyzer from the Controller menu.
This tool, which analyzes setting flows, is used mainly in 2 ways.
Adjustment of measurement set values during start-up
Use sample workpiece images to analyze optimal set values for the processing flow.
Analysis of NG causes during operation
Use logged images to analyze NG causes.
The operation flow is as follows.
Preparation
Re-measurement
Analysis
Correction
Prepare sample workpiece images or logged images
Re-measure in batch
Identify processing items
Correct the set values
6-4-1
Layout of NG Analyzer Window
6 Performing Measurement and Adjustment
6 - 26
FH/FHV Series Vision System User’s Manual (Z365-E1)
