Functional Comparison between the FH-series and FHV-series
Controllers
The following table shows the differences between the FH series and FHV series.
The fastest measurement speed is FH-5000 series. The next speed is the following:FH-5000 series >
FH-3000 series > FH-2000 series > FH-1000 series > FH-L series > FHV series. Select the appropri-
ate Sensor Controller series according to the application as below table.
Principal Difference
Controller model FH Series FHV Series
Function
FH-£050-20 FH-£050-10 FH-£050 FH-L£££-10 FH-L£££
FHV7£-£££
£
Number of Camera
connections
8
*1
4 2 4 2 -
Operation mode
*2
Standard Yes
Double Speed Multi in-
put
Yes
Non-stop adjustent Yes
Multi-line randomtrigger Yes (Maximum 8 lines) No
Number of scenes (number
of line process changes)
128
*3
Input interface
EtherCAT OK -
External storge
USB memory OK -
SD memory card OK -
microSD card - OK
Sysmac Studio support OK -
Menu languages Japanese, English, Simplified Chinese, Traditional, Chinese, Korean, German, French, Spanish, Italian,
Vietnamese, and Polish
Monitor Interface DVI connection (Recognize the recommended resolution automatically)
RGB connection (Resolution XGA 1024×768 dot)
-
*1. Up to four 12-/20.4-megapixel cameras can be connected. Do not connect more than five cameras when using only 12-/20.4-meg-
apixel cameras. When mixing 12-/20.4-megapixel cameras with other cameras, you can connect up to four 12-/20.4-megapixel
cameras and also connect up to four other cameras, so a total of eight cameras can be connected.
*2. Select the Operation mode for your application purpose. For Operation mode, refer to the following: Refer 4-4 Setting Operation
Mode [Startup Settings] on page 4 - 11.
*3. The Conversion Scene Group Data Tool allows you to create a scene group of more than 129 scenes.
