Item
Set value
[Factory default]
Description
Display Type
• No Error Notifi-
cation
• Send Error Noti-
fication
• Dialog Box
• Dialog Box
(Clear ERROR
Signal)
Select the notification or operation of error when specified er-
ror type occurs. The default operation differs by the error
type.
• No Error Notification:
Displays the error information on the Information Pane
when the selected Error Type occurs.
• Send Error Notification:
This Send Error Notification operation is limited to only
Logging Error and PLC Link Error.
For Information Pane, refer to the 8-2-1 Main Window
(Layout 0): Adjustment Window (Default) on page 8 - 9.
• Dialog Box:
Displays the error information on the window when the se-
lected Error Type occurs. When you select ON in ERROR
Signal Output, the error output remains on even if you
close the dialog box.
• Dialog Box (Clear ERROR Signal):
Displays the error information on the window as a dialog
box when the selected Error Type occurs. When you se-
lect ON in ERROR Signal Output, the error output is
turned OFF when you close the dialog box.
Additional Information
A dialog is displayed when Dialog Box (Clear ERROR Signal) occurs. Show an example when
a logging error of Line 0 occurs. Click OK to close the dialog.
4 Setting the Controller
4 - 61
FH/FHV Series Vision System User’s Manual (Z365-E1)
4-18 Setting the Operation at Error [Error Setting]
4
