Omron FHV7 series User Manual

2
Select a scene on the scene list to switch, click Switching at the bottom of the list or double
click the selected scene.
A Confirmation dialog will be displayed.
3 Click Yes.
The current scene is switched to the selected scene.
Loading a scene
1 Select Scene tab on the TDM editor.
A list of scenes is displayed. The current scene has a check mark.
5 Creating Measurement Scenes
5 - 34
FH/FHV Series Vision System User’s Manual (Z365-E1)
