Additional Information
• There are no limitations on when you can perform FTP file transfers.
• Processing of FTP file transfers does not affect the transaction time. However, It does affect
the load on the network.
Precautions for Correct Use
• Use only single-byte alphanumeric characters for the file names of files to send and receive
with the FTP.
If account, or password is needed for FTP connection, set them as follows
- Account: anonymous
- Password: Blank or single-byte alphanumeric characters
• When you access to the external storage device except RAMDisk, refer to the following:
- M:\ (SD memory card): SDDisk
- E:\ (USB memory): USBDisk
- E:\ (microSD card): SDDisk
- F:\ (USB memory): USBDisk2
• There is no FTP access to an external storage device, drive letter with G or higher.
Saving Logged Data Directly to a Shared Folder on a Computer
[Network Drive Function]
The network drive function is useful when you need to log image data or measurement data directly
to a computer that is connected by Ethernet.
You can specify the shared folder on a computer that is connected by Ethernet as the destination for
logged images or logged data.
Direct reading and writing with the computer eliminates the need for reading and writing through exter-
nal storage devices. At the same time, it also eliminates the need to stop measurements to insert or
remove the external storage device.
Computer
FH Controller
Ethernet
Shared folder on computer
(the shared folder must be set up
on the computer)
Saving directly
• Logged images
• Logged data
Set the Controller to save to the
shared folder on the computer.
l
Setting Up the Network Drive
Register the shared folder on a network drive with a shared name.
6 Performing Measurement and Adjustment
6 - 22
FH/FHV Series Vision System User’s Manual (Z365-E1)
