Item
Setting value
[Factory default]
Description
Value type
[Fixed string]
Variable
Specifies the data type to display in the cell.
Value
(Fixed
string)
0 to 255 characters Specifies a fixed character string to display in the cell.
The default characters displayed will be according to the selected
display language (\jpn\\eng\aaa··).
Value (Var-
iable)
- Specifies a variable for the data type to display in the cell.
The default characters displayed for variables will be according to
the selected display language (\jpn\\eng\aaa··).
What is displayed for a variable in the grid display area is the vari-
able name, not the current value of the variable.
Font Setting - -
Size 1 to 100 [12] Sets the font size of the cell.
Style
Bold
Italic
Underline
Strikeout
Sets the font style of the cell.
Check the box of your desired style.
Format - -
Position
Top left
Top center
Top right
[Center left]
Center
Center right
Bottom left
Bottom center
Bottom right
Specifies the display position of a character string to be displayed
in a cell.
Format 0 to 31 characters
[{0}]
Specifies the format.
A value is displayed on the specified position, {0}. For instance, A
value of 1000 is specified and the format is A = {0}, A = 1000 will
be displayed.
Text color R: 0 to 255 [0]
G: 0 to 255 [0]
B: 0 to 255 [0]
Sets the text color of a cell.
Variable - Selects this to make the text color of the cell specified by a varia-
ble.
If variable is set here, the Text color setting is disabled.
Background
color
R: 0 to 255 [255]
G: 0 to 255 [255]
B: 0 to 255 [255]
Specifies the background color of a cell.
Variable - Select this to make the background color of a cell specified by a
variable.
If variable is set here, the Background color setting is disabled.
Format specifier Description Example
E? or e? Expresses an exponent so that the
number of decimas becomes as
specified with ?.
1.235E-001
*1
Value: 0.12345
Format: {0:E3}
F? or f? Displays a numeric string with the
number of decimals specified
with ?.
-123.4568
*1
Value: -123.456789
Format: {0:F4}
8 Setting Windows
8 - 61
FH/FHV Series Vision System User’s Manual (Z365-E1)
