Item
Approximate memory usage
Main settings that affect change of
memory used
Adding to
measurement
flow
Change due to
settings
Shape Search III Approx. 3 KB Approx. 335 MB Model registration figure, model parameters,
saved settings of model registration image,
image size, number of detections, shape of
edge in image.
EC Corner Approx. 62 KB No change -
EC Cross Approx. 34 KB No change -
Classification Approx. 41 KB Approx. 543,477
MB (for mono-
chrome image)
Approx.
1,608,757 MB
(for color image)
Model registration count, model registration
figure, model parameters, image size, wheth-
er image is color or monochrome.
Edge Position Approx. 1 KB Approx. 1 MB Measurement region figure, image size.
Edge Pitch Approx. 5 KB Approx. 1 MB Measurement region figure, image size.
Scan Edge Position Approx. 2 KB Approx. 12 MB Measurement region figure, number of meas-
urement points, image size.
Scan Edge Width Approx. 2 KB Approx. 23 MB Measurement region figure, number of meas-
urement points, image size.
Circular Scan Edge Posi-
tion
Approx. 2 KB Approx. 42 MB Measurement region figure, number of meas-
urement points, image size.
Circular Scan Edge Width Approx. 2 KB Approx. 83 MB Measurement region figure, number of meas-
urement points, image size.
Intersection Approx. 4 KB Approx. 23 MB Measurement region figure, image size.
Color Data Approx. 1 KB Approx. 25 MB Measurement region figure, selected region
figure of static mask, image size.
Gravity and Area Approx. 1 KB Approx. 25 MB Measurement region figure, selected region
figure of static mask, image size.
Labeling Approx. 2 KB Approx. 25 MB Measurement region figure, selected region
figure of static mask, image size, maximum
number of labels.
Label Data Approx. 1 KB No change -
Defect Approx. 20 KB Approx. 51 MB Measurement region figure, selected region
figure of static mask, image size.
Precise Defect Approx. 20 KB Approx. 29 MB Measurement region figure, detection param-
eter settings, selected region figure of static
mask, image size.
Fine Matching Approx. 1 KB Approx. 38 MB
(for mono-
chrome image)
Approx. 63 MB
(for color image)
Model registration figure, image size, wheth-
er image is color or monochrome.
Character inspection Approx. 4 KB No change -
Date Verification Approx. 1 KB Approx. 1 MB Length of character string, code parameter
settings.
Appendices
A - 31
FH/FHV Series Vision System User’s Manual (Z365-E1)
A-10 Memory Usage Guidance For Processing Items
