Item
Approximate memory usage
Main settings that affect change of
memory used
Adding to
measurement
flow
Change due to
settings
Brightness Correct Filter Approx. 1 KB No change -
Color Gray Filter Approx. 1 KB No change -
Extract Color Filter Approx. 1 KB No change -
Anti Color Shading Approx. 1 KB No change -
Stripes Removal Filter II Approx. 1 KB No change -
Polar Transformation Approx. 1 KB Approx. 1 MB Circle radius, circle width, end point overlay,
image size.
Trapezoidal Correction Approx. 1 KB Approx. 1 MB Number and length of calculation expres-
sions.
Machine Simulator Approx. 1 KB No change -
Image Subtraction Approx. 1 KB Approx. 63 MB Model registration figure, image size.
Advanced filter Approx. 9 KB No change -
Panorama Approx. 240 KB Approx. 13 MB Whether brightness correction reference im-
age is used, image size.
Unit Macro Approx. 1 KB Approx. 4 MB Length of program code.
Unit Calculation Macro Approx. 1 KB Approx. 2 MB Length of program code.
Calculation Approx. 1 KB Approx. 1 MB Number and length of calculation expres-
sions, number and length of comments.
Line Regression Approx. 3 KB Approx. 1 MB Number of points, number and length of cal-
culation expressions.
Circle Regression Approx. 2 KB Approx. 1 MB Number and length of calculation expres-
sions.
Precise Calibration Approx. 660 KB Approx. 51 MB Measurement region figure, image size,
specified calibration method.
User Data Approx. 6 KB Approx. 1 MB Number and length of calculation expres-
sions.
Set Unit Data Approx. 1 KB Approx. 1 MB Length of calculation expression.
Get Unit Data Approx. 1 KB No change -
Set Unit Figure Approx. 1 KB Approx. 1 MB Number and length of calculation expres-
sions, number of figures, figure type.
Get Unit Figure Approx. 1 KB No change -
Trend Monitor Approx. 20 KB Approx. 3 MB Length of calculation expression, number of
items saved.
Image Logging Approx. 1 KB Approx. 1 MB Length of calculation expression, length of
sub-folder name, length of prefix.
Data Logging Approx. 1 KB Approx. 1 MB Number and length of calculation expres-
sions, number and length of comments,
length of file name, length of sub-folder
name, length of prefix.
Elapsed Time Approx. 1 KB No change -
Wait Approx. 1 KB No change -
Focus Approx. 1 KB Approx. 13 MB Figure in region settings, image size.
Iris Approx. 1 KB Approx. 13 MB Figure in region settings, image size.
Parallelize Approx. 1 KB No change -
Parallelize Task Approx. 1 KB No change -
Appendices
A - 33
FH/FHV Series Vision System User’s Manual (Z365-E1)
A-10 Memory Usage Guidance For Processing Items
