A-15
List for Processing Item Identifier
l
Measurement
Processing item Identifier Processing item Identifier
Search Search Flexible Search FlexibleSearch
Sensitive Search SensitiveSearch ECM Search EcmSearch
Shape Search II ShapeSearch2 Shape Search III ShapeSearch3
EC Corner EcCorner EC Cross EcCross
Classification Classification Edge Position EdgePosition
Edge Pitch EdgePitch Scan Edge Position ScanEdgePosition
Scan Edge Width ScanEdgeWidth Circular Scan Edge Posi-
tion
CircularScanEdgePosi-
tion
Circular Scan Edge
Width
CircularScanEdgeWidth Intersection Intersection
Color Data ColorData Gravity and Area ColorArea
Labeling ColorLabeling Label Data LabelData
Defect Defect Precise Defect PreciseDefect
Fine Matching FineMatching Character Inspection CharacterInspect
Date Verification DateVerification Model Dictionary ModelDictionary
2DCode II 2dcr2 2DCode 2dcrV400
Barcode BarcodeCC OCR User Dictionary CharacterDictionary
OCR CharacterRecognition Circle Angle CircleAngle
Glue Bead Inspection EmbrocationTrack Search II Search2
l
Input image
Processing item Identifier Processing item Identifier
Camera Image Input CameraImage Camera Image Input FH CameraImageFH
Camera Image Input
FHV
CameraImageFHV Camera Image Input
HDR
CameraImageHDR
Camera Image Input
HDR Lite
CameraImageHDRLite Photometric Stereo Im-
age Input
CameraImagePS
Camera Switching CameraSwitch Measurement Image
Switching
MeasureImageSwitch
Multi-Trigger Imaging MultiImaging *Multi-Trigger Imaging
End
MultiImagingEnd
Multi-Trigger Imaging
Task
MultiImagingTask
Note: An item with * in the head is not displayed.
l
Compensate image
Processing item Identifier Processing item Identifier
Position Compensation Scroll Filtering Filtering
Background Suppression FilterHighContrast Brightness Correct Filter FilterShading
Appendices
A - 51
FH/FHV Series Vision System User’s Manual (Z365-E1)
A-15 List for Processing Item Identifier
