Outputting Data and Controlling Operation through EtherNet/IP
294
FQ2 User’s Manual
● Connection Settings
*1 If multi-cast connections are used, however, use an Ethernet switch that has multi-cast filtering, unless the tag set is received by all nodes
in the network.
*2 Set the same value as you set for the refreshing task period in the EtherNet/IP communications settings.
• If I/O memory addresses are specified for the communications areas, the information in the communications areas
will be cleared when the operating mode of the PLC changes unless addresses in the CIO Area, which are main-
tained, are specified.
• The following assembly object is required to specify instances when the EDS file is not used.
Assembly Object Settings
Parameter Setting
Originator device (PLC) Input tag set PLC_tag_set_name-[**Byte]
**: This is the total size of the response area and
output area that you set.
Connection type Any (default: multi-cast connection)
*1
Output tag set PLC_tag_set_name-[20Byte]
Target device (Vision Sen-
sor)
Output tag set Input_101-[**Byte]
**: This is the total size of the response area and
output area that you set.
Input tag set Output_100-[20Byte]
Packet interval (RPI) Any (default: 20.0)
*2
Parameter name Setting Remarks
Instance ID 100 Output connection
101 Input connection
Important
