System Configuration
28
FQ2 User’s Manual
Connection Compatibility
Yes: Supported, No: Not supported
*1: This applies when an RS-232C Interface Sensor Data Unit is connected.
*2: This applies when a Parallel Interface Sensor Data Unit is connected.
Type of connection to FQ2-S Other connection
EtherNet/IP PLC Link on
Ethernet
TCP no-pro-
tocol commu-
nications on
Ethernet
FINS/TCP
no-protocol
communica-
tions on
Ethernet
RS-232C
*1
Parallel communications
Sensor’s
standard par-
allel commu-
nications
Parallel Inter-
face
*2
EtherNet/IP --- No Yes Yes Yes Yes Yes
PLC Link on Ethernet No --- Yes Yes Yes Yes Yes
TCP no-protocol communi-
cations on Ethernet
Yes Yes --- No No Yes Yes
FINS/TCP no-protocol com-
munications on Ethernet
Yes Yes No --- No Yes Yes
RS-232C
*1
Yes Yes No No --- Yes No
Parallel
communi-
cations
Sensor’s stan-
dard parallel
communica-
tions
Ye s Ye s Ye s Ye s N o - - - N o
Parallel Inter-
face
*2
Ye s Ye s Ye s Ye s N o N o - - -
Connections Across Network Routers
You can connect to a Sensor on a different network than the Touch Finder or PC Tool through a router.
• To connect to a Sensor, directly specify the IP address of the Sensor. Automatic connection to a Sensor is not
possible.
• Use a fixed IP address for the Sensor to connect to.
