Omron fq2

PLC Link Connections
FQ2 User’s Manual
333
Connecting through Ethernet
9
Setting the Output Format
[In/Out] − [I/O setting] − [Output data setting] − [Link data output]
1 Press [Output format].
2 Press [Output form].
3 Set either a floating point decimal or a fixed decimal for the output form.
Item Description Setting range
Output form
Set the output form for numerical data. Floating point or fixed point (default: fixed point)
+0
Output data Assigned output data
+1
Output data 0
(4 bytes)
Output data 1
(4 bytes)
Output data 2
(4 bytes)
Output data 31
(4 bytes)
Output data 32
(4 bytes)
Output data 61
(4 bytes)
Output data 62
(4 bytes)
Output data 63
(4 bytes)
Output data 64
(4 bytes)
Output data 80
(4 bytes)
Output data 81
(4 bytes)
Inspection item 0: Position X for Search
+2
+3
Inspection item 0: Position Y for Search
+4
+5
Inspection item 1: Position X 1st point for Shape Search II
+62
+63
Inspection item 1: Position X 30th point for Shape Search II
+64
+65
Inspection item 1: Position Y 1st point for Shape Search II
+122
+123
Inspection item 1: Position Y 30th point for Shape Search II
+124
+125
Inspection item 2: Position X 1st point for Shape Search II
+126
+127
Inspection item 2: Position Y 1st point for Shape Search II
+128
+129
Inspection item 2: Position X 2nd point for Shape Search II
+160
+161
Inspection item 2: Position X 10th point for Shape Search II
+162
+163
Inspection item 2: Position Y 10th point for Shape Search II
256 bytes
(This data
is output.)
Offset from first
address in output area
72 bytes
The data that
exceeds the
set upper limit
is discarded.
▲
