Controlling Operation and Outputting Data with TCP No-protocol Communications
FQ2 User’s Manual
355
Connecting through Ethernet
9
Setting the Output Format
[In/Out] − [I/O setting] − [Output data setting] − [Noprotocol data output]
1 Press [Output format].
2 Set [Output form] to [ASCII] or [Binary].
3 Set the data format for the data form that you select-
ed.
ASCII
Binary
Item Description Setting range
For ASCII Digits of
integer
Sets the number of digits in the integer part
of the number.
1 to 10 digits
Default: 6 digits
Digits of
decimal
Set the number of digits in the integer part. 0 to 4 digits
Default: 4 digits
Negative
Sets the way to express negative numbers. − or 8
Default: −
0 Sup-
pressed
Sets whether to use zero suppression. Yes or No
Default: No
Field sepa-
rator
Sets the field separator. OFF, comma, tab, space, CR, LF,
or CR+LF
Default: OFF
Record
separator
Sets the record separator. OFF, comma, tab, space, CR, LF,
or CR+LF
Default: OFF
For Binary Decimal
output form
Set the decimal output form for numerical
data.
Floating point or fixed point
(default: Fixed point)
▲
