Controlling Operation and Outputting Data with FINS/TCP No-protocol Commands
386
FQ2 User’s Manual
Set Image Adjustment Data: 280F 00501010
This command sets parameters or measurement values from a position compensation item or filter item.
● Format
● Response Format
● End Codes
● Parameter Descriptions
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Position compensation item/filter
item number (4 bytes)
External reference
number (4 bytes)
Set value (4 bytes)
28 0F 00501010 Position compensation item/filter
item number 0 to 7 (1 digit max.)
External reference
number
Setting
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00501010
End code (hex) Meaning
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Position compensation
item number
Specifies the number of the position compensation item or filter item to set.
External reference num-
ber
Specifies the external reference number.
12-2 External Reference Parameters: p. 430
Set value Specifies the set value.
12-2 External Reference Parameters: p. 430
