Controlling Operation and Outputting Data with FINS/TCP No-protocol Commands
FQ2 User’s Manual
387
Connecting through Ethernet
9
Getting the Inspection Item Data: 280F 00401020
This command acquires the parameters and measurement values of the specified inspection item.
Format
Response Format
End Codes
Parameter Descriptions
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Inspection item number (4 bytes) External reference
number (4 bytes)
28 0F 00401020 Inspection item number from 00
to 1F (2 digits max.)
External reference
number
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
Acquired value (4
bytes)
28 0F End code 00401020 Acquired value
(1,000 times the
actual value)
End code (hex) Meaning
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Inspection item number Specifies the number of the inspection item for which to acquire the data.
External reference num-
ber
Specifies the external reference number.
12-2 External Reference Parameters: p. 430
Acquired value Returns the data for the specified inspection item.
12-2 External Reference Parameters: p. 430
