Controlling Operation and Outputting Data with FINS/TCP No-protocol Commands
388
FQ2 User’s Manual
Setting the Inspection Item Data: 280F 00501020
This command sets the parameters and measurement values of the specified inspection item.
● Format
● Response Format
● End Codes
● Parameter Descriptions
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Inspection item number (4 bytes) External reference
number (4 bytes)
Set value (4 bytes)
28 0F 00501020 Inspection item number from 00
to 1F (2 digits max.)
External reference
number
Set value (1,000
times the actual
value)
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00501020
End code (hex) Meaning
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Inspection item number Specifies the number of the inspection item to set.
External reference num-
ber
Specifies the external reference number.
12-2 External Reference Parameters: p. 430
Setting Specifies the set value.
12-2 External Reference Parameters: p. 430
