Menu Tables
FQ2 User’s Manual
421
Appendices
12
Calibration
Select Sets a registered calibration pattern. Calibration data 0 to 31 Scene ---
Modify Used to edit calibration data. Calibration data 0 to 31 Scene ---
Specify point Sets the type of calibration data to set. --- --- p. 194
Reference --- --- p. 196
Parameter --- --- p. 198
Modify Sets the parameters for the calibration
data.
--- --- ---
(Specify point)
Specify point coord.
Sets the Camera coordinates. --- Calibra-
tion data
p. 194
Actual coord.
Sets the Camera coordinates and the
actual coordinates.
Point coordinate: 0 to 9999
Actual coordinate: 0 to 99999.9999
Calibra-
tion data
(Reference sampling)
Model region
Used to edit the model regions.
The procedure is the same as for setting
the model region for a Search inspection
item.
--- Calibra-
tion data
p. 197
Insp. region
Changes the size and position of the
measurement region.
--- Calibra-
tion data
Actual coord.
Sets the Camera coordinates and the
actual coordinates.
Point coordinate: 0 to 9999
Actual coordinate: 0 to 99999.9999
Calibra-
tion data
(Parameter)
Coordi-
nate
Sets the positive direction when specify-
ing coordinates.
Righthand, Lefthand
(default)
Calibra-
tion data
p. 198
Origin Select the location of the origin of the
coordinate system.
Lowerleft, Upperleft (default), or Center Calibra-
tion data
Magnifica-
tion
Set the actual dimension that corre-
sponds to one pixel.
0.0001 to 9.9999 (
default
:1.0000) Calibra-
tion data
Clear Clears the parameter settings for the cal-
ibration data.
--- --- ---
Copy Copies the calibration data. --- --- ---
Rename Changes the name of the calibration
data.
15 alphanumeric characters max. --- ---
Menu command Description Setting range Data Refer-
ence
To Next Page
