Page #425 background imageLoading...
Page #425 background image
Menu Tables
FQ2 User’s Manual
423
Appendices
12
Sensor settings
Startup set-
tings
Startup
mode
Sets whether the startup scene number
is set manually.
ON or OFF (Scene number when set-
tings were saved is startup scene num-
ber.)
System p. 192
Startup
scene
Set the scene number to use at startup. Standard models: 0 to 31, Single-func-
tion models: 0 to 7, Default: 0
Password
settings
Password
ON/OFF
Enables (ON) or disables (OFF) the
password.
OFF (default) or ON System p. 223
Enter
password
Sets a password. 15 characters max.
Adjustment mode in
Run
Sets whether to adjust measurement
contents in Run Mode.
OFF (default) or ON --- p. 187
Network settings
Ethernet p. 53
IP address set-
ting
Sets the method to use to set IP
addresses.
Auto (default), Fixed, DHCP System
IP address Enter the IP address of the Sensor.
(Valid only when the [IP address setting]
is set to [Fixed].)
a.b.c.d
a: 1 to 223
b: 0 to 255
c: 0 to 255
d: 2 to 254
(Default: 10.5.5.100)
System p. 53
Subnet mask Inputs the subnet mask.
(Valid only when the [IP address setting]
is set to [Fixed].)
0.0.0.0 to 255.255.255.255
(Default: 255.255.255.0)
System p. 53
Gateway Sets the default gateway address. (When
the [IP address setting] is set to [Fixed].)
1.0.0.1 to 223.255.255.254
(Default: 10.5.5.7)
System
Data output
No-protocol data
Communication
type
Sets the communications type to use to
output no-protocol data.
Invalid (default), No protocol (TCP), No
protocol (FINS), No protocol (RS-232C)
System p. 351,
p. 394
When the com-
munications type
is TCP no-proto-
col or FINS/TCP
no-protocol
Connec-
tion mode
Sets whether to communicate with the
communications devices as a server
device or a client device.
TCP server (default), TCP client System p. 351
IP
address
Sets the IP address to which to output
no-protocol data.
* Setting is not possible if the connection
mode is set to a TCP server.
a.b.c.d
a: 1 to 223
b: 0 to 255
c: 0 to 255
d: 1 to 254
(Default:10.5.5.111)
System p. 351
Port No. Sets the output port number.
* Setting is not possible if the connection
mode is set to a TCP server.
0 to 65535 (Default: 9600) System p. 351
