Omron fq2 User Manual

Menu Tables
424
FQ2 User’s Manual
Sensor settings
Data output
No-protocol data
When the com-
munications type
is RS-232C no-
protocol
Baud rate Set the baud rate to use for RS-232C
communications.
2400, 4800, 9600, 19200, 38400, 57600,
or 115200 (default: 38400)
System p. 394
Data
length
Sets the data length. 7bit or 8bit (default: 8bit) System p. 394
Parity Sets the parity. None, Odd, Even (default: None) System p. 394
Stop bit Sets the number of stop bits. 1bit, 2bit (default: 1bit) System p. 394
Flow con-
trol
Sets the controls for the flow of commu-
nications with the software.
None, Xon/Xoff (default: None) System p. 394
Delimiter Set the delimiter to add to the end of
commands and responses.
CR, LF, or CR+LF (default:CR) System p. 394
Interval
timeout
(text)
Timeout [s] Set the time in seconds to
generate a timeout error.
1 to 120 s, 0: Not monitored.
(default: 0 s)
System p. 394
Interval
time-
out(after
Xoff
reception)
Timeout [s] Set the time in seconds to
generate a timeout error.
1 to 120 s, 0: Not monitored.
(default: 0 s)
System p. 394
Link data output
Communication
type
Sets the communications type to use for
EtherNet/IP or PLC Link outputs.
Invalid (default), PLC link (SYSMAC)
PLC link (MELSEC), EtherNet/IP
System p. 327
Area set-
tings(Only when
communications
type is PLC Link)
p. 328
Command
Area type
Sets the area to write command data to
the Sensor.
Control inputs, command codes, and
command parameters are written to this
area.
PLC Link (SYSMAC CS/CJ/CP/One)
CIO Area (CIO) (default)
Work Area (WR)
Holding Bit Area (HR)
Auxiliary Bit Area (AR)
DM Area (DM)
EM Area (EM0 to EMC)
PLC Link (MELSEC QnU/Q/QnAS)
Data Register
File Register
Link Register
System
Address
Set the first address of the command
area.
0 to 99,999 (default: 0) System
Menu command Description Setting range Data Refer-
ence
