Menu Tables
FQ2 User’s Manual
425
Appendices
12
Sensor settings
Data output
Link data output
Area settings
Response
Area type
Sets the area to write execution results
from the Sensor.
Control outputs, command codes,
response codes, and response data
CIO Area (CIO) (default), Work Area
(WR), Holding Bit Area (HR), Auxiliary
Bit Area (AR), DM Area (DM), EM Area
(EM0 to EMC)
System p. 328
Address
Set the first address of the response area. 0 to 99999 (default: 100) System
Output
Area type
Sets the area to write output data from
measurements.
Output data 0 to 31
CIO Area (CIO) (default)
Work Area (WR)
Holding Bit Area (HR)
Auxiliary Bit Area (AR)
DM Area (DM)
EM Area (EM0)
EM Area (EM1)
:
EM Area (EMC)
System p. 328
Address
Set the first address of the output area . 0 to 99999 (default: 200) System
Output hand-
shake
Sets whether to establish an interlock
with the PLC when data is output.
No (default) or Yes System p. 328
Retry details Enables or disables retrying communications.
This can be set only when the communi-
cations type is set to a PLC Link.
ON or OFF (default) System p. 328
Retry interval Sets the interval for retrying communications.
This setting is enabled only when [Retry
details] is set to [ON].
This can be set only when the communi-
cations type is set to a PLC Link.
0 to 2,147,483,647 ms (default:10,000
ms)
System p. 328
Max output data Sets the upper limit of the number of out-
put data to use for PLC Link outputs.
Any output data that is beyond this value
is discarded.
This can be set only when the communi-
cations type is set to a PLC Link.
32 to 1024 (default: 256) System p. 328
Output data size Sets the data size to output for EtherNet/
IP output.
If the data size that is set is exceeded,
data will be output in more than one
transfer.
This can be set only when the communi-
cations type is set to EtherNet/IP.
32 bytes (default), 64 bytes, 128 bytes, or
256 bytes
System p. 290
Connection
mode
Sets the TPC connection mode. TCP server (default) or TCP client System p. 328
Refreshing task
period
Set the communications cycle for cyclic
tag data link communications for the
Vision Sensor.
4 to 10,000 ms (default:10 ms) System p. 290
Timeout Sets the timeout time when handshaking
is enabled.
0.1 to 120.0 s (default: 10 s) System p. 291
Data output
period
Set the period for outputting measure-
ment results.
This parameter is displayed and can be
set only when [Handshake setting] is set
to [No].
2 to 5,000 ms (default: 40 ms) System p. 291
GATE signal ON
period
Set the time to turn ON the GATE signal.
This parameter is displayed and can be
set only when [Handshake setting] is set
to [No].
1.0 to 1,000.0 ms (default: 20.0 ms) System p. 291
Initialize Initializes the Sensor settings and saved
data.
--- --- p. 229
Restart Restarts the Sensor. --- ---
Update Updates the Sensor system to the most
recent data.
--- --- p. 491
Menu command Description Setting range Data Refer-
ence
