External Reference Parameters
FQ2 User’s Manual
435
Appendices
12
150 Detec-
tion point
coordi-
nate
Detection point X Setting/Acqui-
sition
0 to 9,999 0 --- ---
151 Detection point Y Setting/Acqui-
sition
0 to 9,999 0 --- ---
156 Mea-
sure-
ment
condition
Model mode Setting/Acqui-
sition
0: Stable, 1: High-speed 0 --- ---
160 Judge-
ment
condi-
tions
Judgement upper limit
for search coordinate X
Setting/Acqui-
sition
−99,999.9999 to 99,999.9999 99,999.9
999
--- Adjust judge-
ment
161 Judgement lower limit
for search coordinate X
Setting/Acqui-
sition
−99,999.9999 to 99,999.9999 −
99,999.9
999
--- Adjust judge-
ment
162 Judgement upper limit
for search coordinate Y
Setting/Acqui-
sition
−99,999.9999 to 99,999.9999 99,999.9
999
--- Adjust judge-
ment
163 Judgement lower limit
for search coordinate Y
Setting/Acqui-
sition
−99,999.9999 to 99,999.9999 −
99,999.9
999
--- Adjust judge-
ment
164 Judgement upper limit
for search angle
Setting/Acqui-
sition
−180 to 180 180 --- Adjust judge-
ment
165 Judgement lower limit
for search angle
Setting/Acqui-
sition
−180 to 180 −180 --- Adjust judge-
ment
166 Judgement upper limit
for correlation
Setting/Acqui-
sition
0 to 100 100 --- Adjust judge-
ment
167 Judgement lower limit
for correlation
Setting/Acqui-
sition
0 to 100 60 --- Adjust judge-
ment
168 Position compensation
X upper limit
Setting/Acqui-
sition
−99,999.9999 to 99,999.9999 99,999.9
999
--- Adjust judge-
ment
169 Position compensation
X lower limit
Setting/Acqui-
sition
−99,999.9999 to 99,999.9999 −
99,999.9
999
---
Ad
just judge-
ment
170 Position compensation
Y upper limit
Setting/Acqui-
sition
−99,999.9999 to 99,999.9999 99,999.9
999
--- Adjust judge-
ment
171 Position compensation
Y lower limit
Setting/Acqui-
sition
−99,999.9999 to 99,999.9999 −
99,999.9
999
--- Adjust judge-
ment
172 Theta position compen-
sation upper limit
Setting/Acqui-
sition
−180 to 180 180 --- Adjust judge-
ment
173 Theta position compen-
sation lower limit
Setting/Acqui-
sition
−180 to 180 −180 --- Adjust judge-
ment
310 Logging
condi-
tions
Data logging switch for
entire unit
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
311 Data logging switch for
judgement
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
312 Data logging switch for
scroll X
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
313 Data logging switch for
scroll Y
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
315 Data logging switch for
position X
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
316 Data logging switch for
position Y
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
321 Data logging switch for
correlation
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
External
refer-
ence
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
