Specifications and Dimensions
FQ2 User’s Manual
487
Appendices
12
• Parallel Cable for FQ-SDU2
• Sensor Data Unit Cable
Do not bend any Cable beyond the specified minimum bending radius. Doing so may damage the Cable.
• AC Adapter
Item Model FQ-VP2002 FQ-VP2005 FQ-VP2010
Applicable Units FQ-SDU2@
Cable length 2 m 5 m 10 m
Cable type Flat cable
Minimum bending radius 5.5 mm
Weight 80 g 200 g 400 g
Item Model FQ-WU002 FQ-WU005 FQ-WU010 FQ-WU020
Cable length 2 m 5 m 10 m 20 m
Cable type Robot cable
Cable diameter 7
Minimum bending radius 35 mm
Weight 200 g 400 g 800 g 1500 g
Item Model FQ-AC1 FQ-AC2 FQ-AC3 FQ-AC4 FQ-AC5 FQ-AC6
Plug type AAACBFO
Certified standards PSE UL/CSA CCC mark --- --- ---
Input voltage 100 to 240 VAC (90 to 264 VAC)
Input current 0.4 A max., 100 VAC, 50 Hz when connected to maximum load
Input frequency 47 to 63 Hz
Output voltage 15 VDC±5%
Output current 1 A max.
Ambient temperature
range
Operating: 0 to 40°C
Storage: −20 to 65°C (with no icing or condensation)
Ambient humidity range Operating and storage: 35% to 80% (with no condensation)
Material Case: PPE
Cable length 1.5 m
Dimensions 78 × 50 × 30 mm (without power cable)
Weight Approx. 270 g
Contents of label on AC
Adapter
