Detailed EtherNet/IP Communications Specifications
FQ2 User’s Manual
503
Appendices
12
1-2 02h Message Router Object
Class Attributes
None
Instance Attributes
None
Services
None
1-3 06h Connection Manager
Class Attributes
None
Instance Attributes
None
Services
1-4 F5h TCP/IP Interface
Class Attributes
Instance Attributes
Code Service name Class Instances Remarks
54 hex Forward Open No Yes
4E hex Forward Close No Yes
ID Access Name Data type Description Attribute value
1 Get Revision UINT Revision of the object 1
2 Get Max Instance UINT Maximum instance number 1
3 Get Num Instance UINT Number of object instances 1
ID Access Name Data type Description Attribute value
1 Get Status DWORD Interface status 0x0002 (Depends
on the device.)
2 Get Configuration Capability DWORD Interface Function Flag 0x0002 (Depends
on the device.)
3 Get/Set Configuration Control DWORD Interface Control Flag 0x0000
4 Get Physical Link Object STRUCT of: Path to the link object in the
physical layer
---
Path size UINT Path size 2
Path Padded
EPATH
Segment to identify physical-
layer linked object
20 F6 24 01
