Detailed EtherNet/IP Communications Specifications
504
FQ2 User’s Manual
Services
1-5 F6h Ethernet Link
Class Attributes
Instance Attributes
Services
5 Get Interface Configuration STRUCT of: TCP/IP network interface set-
tings
IP Address UDINT IP address of the device
Network Mask UDINT Network mask of the device
Gateway Address UDINT Default gateway address
Name Server UDINT Primary name server
Name Server 2 UDINT Secondary name server
Domain Name STRING Default domain name
6 Get Host Name STRING Host name
Code Service name Class Instances Remarks
01 hex Get_Attribute_All No Yes
02 hex Set_Attribute_All No Yes
0E hex Get_Attribute_Single No Yes
10 hex Set_Attribute_Single No Yes
ID Access Name Data type Description Attribute value
1 Get Revision UINT Revision of the object 1
2 Get Max Instance UINT
Maximum instance number
1
3 Get Num Instance UINT Number of ports for which
instances are created
1
ID Access Name Data type Description Attribute value
1 Get Interface Speed UDINT Interface baud rate
2 Get Interface Flags DWORD Interface Status Flag
3 Get Physical Address ARRAY of 6
USINTs
MAC-layer address
Code Service name Class Instances Remarks
01 hex Get_Attribute_All No Yes
0E hex Get_Attribute_Single Yes Yes
ID Access Name Data type Description Attribute value
