Omron NJ501-1500

2 Instruction Descriptions
2-240
NJ-series Instructions Reference Manual (W502)
The following table shows the valid ranges for In and Out according to their data types.
• To convert an integer to a bit string, use a **_TO_*** (Integer-to-Bit String Conversion Group) instruc-
tion (page 2-235).
• To convert data with any data type to a bit string, use a TO_** (Bit String Conversion Group) instruc-
tion (page 2-279).
• Always use the correct instruction name for the data types of In and Out.
• If the data size of Out is larger than the data size of In, the upper digits of Out will contain 0.
Data type
of In
Data type
of Out
Valid range for In Valid range for Out
BYTE
USINT
16#00 to 16#FF
0 to 255
UINT
UDINT
ULINT
SINT
−128 to 127
INT
DINT
LINT
WORD
USINT 16#00 to 16#FF 0 to 255
UINT
16#0000 to 16#FFFF 0 to 65535UDINT
ULINT
SINT 16#00 to 16#FF −128 to 127
INT
16#0000 to 16#FFFF −32768 to 32767DINT
LINT
DWORD
USINT 16#00 to 16#FF 0 to 255
UINT 16#0000 to 16#FFFF 0 to 65535
UDINT
16#0000_0000 to 16#FFFF_FFFF 0 to 4294967295
ULINT
SINT 16#00 to 16#FF −128 to 127
INT 16#0000 to 16#FFFF −32768 to 32767
DINT
16#0000_0000 to 16#FFFF_FFFF −2147483648 to 2147483647
LINT
LWORD
USINT 16#00 to 16#FF 0 to 255
UINT 16#0000 to 16#FFFF 0 to 65535
UDINT 16#0000_0000 to 16#FFFF_FFFF 0 to 4294967295
ULINT
16#0000_0000_0000_0000 to
16#FFFF_FFFF_FFFF_FFFF
0 to 18446744073709551645
SINT 16#00 to 16#FF −128 to 127
INT 16#0000 to 16#FFFF −32768 to 32767
DINT 16#0000_0000 to 16#FFFF_FFFF −2147483648 to 2147483647
LINT
16#0000_0000_0000_0000 to
16#FFFF_FFFF_FFFF_FFFF
-9223372036854775808 to
9223372036854775807
Additional Information
Precautions for Correct Use
WORD data INT data
WORD#16#1234
4660
In Out=abc
