2 Instruction Descriptions
2-356
NJ-series Instructions Reference Manual (W502)
• While Reset is TRUE, the register is not shifted even if ShiftL or ShiftR changes to TRUE.
• The register is not shifted if both ShiftL and ShiftR change to TRUE at the same time.
• ENO will change to TRUE when ShiftL or ShiftR changes to TRUE and the shift operation is per-
formed normally, or when Reset is TRUE and the reset operation is performed normally.
• The InOut[] does not change if the value of Size is 0.
• An error occurs in the following case. ENO will be FALSE, and InOut[] will not change.
• The value of Size exceeds the array area of InOut[].
Related System-defined Variables
Name Meaning Data type Description
P_CY Carry (CY) Flag BOOL Value stored in Carry Flag
Precautions for Correct Use
To Next Page
