Variable
Data type Initial value
ST
IF (A=TRUE) THEN
TON_instance0(In:=TRUE, PT:=T#5s, Q=>B);
ELSE
TON_instance0(In:=FALSE, Q=>B);
END_IF;
IF (A=FALSE) THEN
TON_instance1(In:=TRUE, PT:=T#5s, Q=>C);
ELSE
TON_instance1(In:=FALSE, Q=>C);
END_IF;
IF (B=TRUE) OR (C=TRUE) THEN
SetAlarm(
Code:=UINT102,
Info1 :=Abc,
info2 :=Def);
END_IF;
IF (F=TRUE) & (B=FALSE) & (C=FALSE) & (_AlarmFlag<>WORD#16#0000) THEN
ResetAlarm(Code:=UINT#102);
END_IF;
// Check the value of variable A.
// Create user-defined error.
// Reset user-defined error.
A
B
C
F
Abc
Def
TON_instance0
TON_instance1
False
False
False
False
123
456
BOOL
BOOL
BOOL
BOOL
UINT
UINT
TON
TON
_AlarmFlag
WORD
Constant
Variable
Data type Comment
External
Variables
Error Status of User-defined Errors
Internal
Variables
