CIPClose
The CIPClose instruction closes the CIP class 3 connection to the specified handle.
The CIPClose instruction closes the CIP class 3 connection specified with the handle Handle.
The data type of Handle is structure _sCIP_HANDLE. The specifications are as follows:
The following figure shows a programming example.
Instruction Name
FB/
FUN
Graphic expression ST expression
CIPClose Close CIP
Class 3 Con-
nection
FB CIPClose_instance(Execute,
Handle, Done, Busy, Error,
ErrorID, ErrorIDEx);
