2-383
2 Instruction Descriptions
NJ-series Instructions Reference Manual (W502)
Conversion Instructions
2
Gray
Refer to the user documentation for your rotary encoder for the values to specify for Resolution and
ERC.
An error occurs in the following cases. ENO will be FALSE, and Out will not change.
• The value of Resolution is outside of the valid range.
• The value of ERC exceeds the resolution that is specified in Resolution.
• The value of ZPC exceeds the resolution that is specified in Resolution.
• In, when converted to a bit string, is smaller than the value of ERC.
• The value of the bit string after correction for ERC exceeds the resolution that is specified in Resolu-
tion.
Additional Information
Precautions for Correct Use
