1 Instruction Set
1-4
NJ-series Instructions Reference Manual (W502)
Comparison
Instructions
GTascii Text String
Comparison
Greater Than
Performs a greater than comparison between
text strings.
2-95
GEascii Text String
Comparison
Greater Than or
Equal
Performs a greater than or equal comparison
between text strings.
2-95
Cmp Compare Compares two values. 2-98
ZoneCmp Zone Comparison Determines if the comparison data is within the
specified maximum and minimum values.
2-100
TableCmp Table Comparison Compares the comparison data with multiple
defined ranges in a comparison table.
2-102
AryCmpEQ Array Comparison
Equal
Determines if the corresponding elements of
two arrays are equal.
2-105
AryCmpNE Array Comparison
Not Equal
Determines if the corresponding elements of
two arrays are not equal.
2-105
AryCmpLT Array Comparison
Less Than
Performs a less than comparison between the
corresponding elements of two arrays.
2-107
AryCmpLE Array Comparison
Less Than Or
Equal
Performs a less than or equal comparison
between the corresponding elements of two
arrays.
2-107
AryCmpGT Array Comparison
Greater Than
Performs a greater than comparison between
the corresponding elements of two arrays.
2-107
AryCmpGE Array Comparison
Greater Than Or
Equal
Performs a greater than or equal comparison
between the corresponding elements of two
arrays.
2-107
AryCmpEQV Array Value
Comparison Equal
Determines if the elements of an array are
equal to a value.
2-110
AryCmpNEV Array Value
Comparison Not
Equal
Determines if the elements of an array are not
equal to a value.
2-110
AryCmpLTV Array Value
Comparison Less
Than
Performs a less than comparison between a
value and the elements of an array.
2-112
AryCmpLEV Array Value
Comparison Less
Than Or Equal
Performs a less than or equal comparison
between a value and the elements of an array.
2-112
AryCmpGTV Array Value
Comparison
Greater Than
Performs a greater than comparison between a
value and the elements of an array.
2-112
AryCmpGEV Array Value
Comparison
Greater Than Or
Equal
Performs a greater than or equal comparison
between a value and the elements of an array.
2-112
Timer Instruc-
tions
TON On-Delay Timer Outputs TRUE when the set time elapses after
the timer starts.
2-116
TOF Off-Delay Timer Outputs FALSE when the set time elapses
after the timer starts.
2-120
TP Timer Pulse Outputs TRUE while the set time elapses after
the timer starts.
2-123
AccumulationTimer Accumulation
Timer
Totals the time that the timer input is TRUE. 2-126
Timer Hundred-ms Timer Outputs TRUE when the set time elapses after
the timer starts. Set the time in increments of
100 ms. The timing accuracy is 100 ms.
2-129
Type Instruction Name Function Page
