1-9
1 Instruction Set
NJ-series Instructions Reference Manual (W502)
Instruction Set
1
Data Movement
Instructions
AryExchange Array Data
Exchange
Exchanges the elements of two arrays. 2-333
AryMove Array Move Moves one or more array elements. The data
types of the move source and move destina-
tion can be different.
2-335
Clear Initialize Initializes a variable. 2-337
Copy**ToNum (Bit
String to Signed Inte-
ger)
Bit Pattern Copy
(Bit String to
Signed Integer)
Group
Copies the content of a bit string directly to a
signed integer.
2-339
Copy**To*** (Bit String
to Real Number)
Bit Pattern Copy
(Bit String to Real
Number) Group
Copies the content of a bit string directly to a
real number.
2-341
CopyNumTo** (Signed
Integer to Bit String)
Bit Pattern Copy
(Signed Integer to
Bit String) Group
Copies the content of a signed integer directly
to a bit string.
2-343
CopyNumTo** (Signed
Integer to Real Num-
ber)
Bit Pattern Copy
(Signed Integer to
Real Number)
Group
Copies the content of a signed integer directly
to a real number.
2-345
Copy**To*** (Real
Number to Bit String)
Bit Pattern Copy
(Real Number to
Bit String) Group
Copies the content of a real number directly to
a bit string.
2-347
Copy**ToNum (Real
Number to Signed Inte-
ger)
Bit Pattern Copy
(Real Number to
Signed Integer)
Group
Copies the content of a real number directly to
a signed integer.
2-349
Shift Instructions AryShiftReg Shift Register Shifts a bit string one bit to the left and inserts
the input value to the least-significant bit. The
bit string consists of array elements.
2-352
AryShiftRegLR Reversible Shift
Register
Shifts a bit string one bit to the left or right and
inserts the input value to the least-significant or
most-significant bit. The bit string consists of
array elements.
2-354
ArySHL Array N-element
Left Shift
Shifts array elements by one or more elements
to the left (toward the higher elements).
2-357
ArySHR Array N-element
Right Shift
Shifts array elements by one or more elements
to the right (toward the lower elements).
2-357
SHL N-bit Left Shift Shifts a bit string by one or more bits to the left
(toward the higher bits).
2-360
SHR N-bit Right Shift Shifts a bit string by one or more bits to the
right (toward the lower bits).
2-360
NSHLC Shift N-bits Left
with Carry
Shifts an array of bit strings that includes the
Carry (CY) Flag by one or more bits to the left
(toward the higher elements).
2-362
NSHRC Shift N-bits Right
with Carry
Shifts an array of bit strings that includes the
Carry (CY) Flag by one or more bits to the right
(toward the lower elements).
2-362
ROL Rotate N-bits Left Rotates a bit string by one or more bits to the
left (toward the higher bits).
2-364
ROR Rotate N-bits Right Rotates a bit string by one or more bits to the
right (toward the lower bits).
2-364
Conversion
Instructions
Swap Swap Bytes Swaps the upper byte and lower byte of a 16-
bit value.
2-368
Neg Reverse Sign Reverses the sign of a number. 2-369
Type Instruction Name Function Page
To Next Page
